A revolution in exposure technology, our flagship MLP system is the next-gen solution for resin printer OEMs looking to move on from DLP and SLA.

Multi-Laser Patterning module (MLP)

A modular, multi-laser exposure unit for high resolution, high productivity printing, independent of build plate size and fill ratio. Configurable for top-down or bottom-up printing, the MLP’s versatility and performance make it suitable for an incredible variety of machine and resin combinations.

Lasers: 20 vertical beams
Nominal resolution: 20 µm (5 - 40 µm)
Wavelengths: 405 nm (385, 640, 1064 on roadmap)
Power: 1000 – 4000 mW

At the heart of every MLP module is an octagonal prism that makes our process possible. But this heart doesn’t beat, it spins. Sitting on high-speed bearings, the spinning of this polygon allows the beam from each diode fired through it to obtain a surface scanning speed of over 25 m/s, whilst maintaining a perpendicular interaction with the resin surface.
Each of the 20 diodes in each MLP module can address spots of 20 microns (and smaller in upcoming models).
The modular design of the MLP module allows the easy addition of further modules that work in parallel, extending the build size each time without sacrificing layer time or the perpendicularity of the beams.

Resin suitability testing

We are currently demonstrating the capability of our MLP modules on various industrial resins, using our in house test and demonstration platform, the AMS One.

It is important that our customers are confident in both the excellent form accuracy and the material and mechanical properties achieved when using an MLP system.

Meet the team

Roeland Brugman

FOUNDER
Roeland started at the AMSYSTEMS Center in 2018 to valorize the existing IP held by TNO relating to Industrial AM, establishing AMSYSTEMS B.V. in 2020 to further this aim. Roeland has always been active in bringing novel production technologies to industrial applications.
Sander Korten

PRODUCT OWNER & PM
Sander is a creative engineer with experience in industrialization of mechanics, electronics and software (ASML & Vanderlande), in addition to several years of international experience as a commissioning engineer learning a hands-on, pragmatic approach in the field.
Sam Brown

AM SPECIALIST
Sam brings over ten years of experience in additive manufacturing, spanning production and process development, with skills and knowledge gained from working with start-ups, research institutes, and during his PhD at the University of Cambridge.
Sajjad Sefidgar

SOFTWARE ENGINEER
Sajjad is a software engineer with expertise in embedded systems and software development. He brings hands-on experience in designing efficient, high-performance solutions for complex hardware-software integrations.
Jac Jamar

EXPERT CONSULTANT
Jac was the initial system architect for TNO’s ‘Lepus’ 3D printers, from which the MLP exposure technology has been developed by AMSYSTEMS. A physicist at heart, Jac brings decades of experience in the development of high-tech opto-mechatronic equipment for industry.
Shaoxian Zhang

BUSINESS REP - CHINA
For business development in China, Roeland has been working with Dr. Zhang for over 15 years. Shaoxian obtained his PhD at TU/e, and after 4 years at ASML he created his own entity in the Brainport region to promote business relations between the Netherlands and China.
